Pont y Cafnau Tramroad Bridge

A Scheduled Monument in Park (Parc), Merthyr Tydfil (Merthyr Tudful)

Approximate Location Map
Large Map »
Street or Overhead View
Contributor Photos »

If Google Street View is available, the image is from the best available vantage point looking, if possible, towards the location of the monument. Where it is not available, the satellite view is shown instead.


Latitude: 51.7546 / 51°45'16"N

Longitude: -3.3956 / 3°23'44"W

OS Eastings: 303764

OS Northings: 207138

OS Grid: SO037071

Mapcode National: GBR HN.0LM1

Mapcode Global: VH6CY.3577

Entry Name: Pont y Cafnau Tramroad Bridge

Scheduled Date:

Source: Cadw

Source ID: 317

Cadw Legacy ID: GM424

Schedule Class: Transport

Category: Bridge

Period: Post Medieval/Modern

County: Merthyr Tydfil (Merthyr Tudful)

Community: Park (Parc)

Built-Up Area: Merthyr Tydfil

Traditional County: Glamorgan


The monument consists of the remains of a bridge constructed in 1793 by the Cyfarthfa Ironworks Company. The purpose of the bridge was to carry limestone and water via a tramroad, across the River Taff to the adjoining works on the opposite side of the Taff. The bridge's design was unusual in that it comprised of three tiers: a tramroad, a trough underneath the tramroad to carry water and above the tramroad a wooden launder to carry a further water supply. Apart from the upper launder, the structure was made entirely out of cast iron at the ironworks. Masonry abutments support a pair of massive cast iron 'A' shaped ties which are mortised into a central vertical 'king post'. The decking of the bridge retains the chairs and seating for the original tramroad (4ft gauge).

The monument is of national importance for its potential to enhance our knowledge of industrial period construction techniques and transportation systems. It retains significant archaeological potential, with a strong probability of the presence of associated archaeological features and deposits. The structure itself may be expected to contain archaeological information concerning chronology and building techniques.

The scheduled area comprises the remains described and areas around them within which related evidence may be expected to survive.
