Lime kilns, associated tramways, structures and other buildings at Llanymynech

A Scheduled Monument in Llanymynech and Pant, Shropshire

More Photos »
Approximate Location Map
Large Map »

If Google Street View is available, the image is from the best available vantage point looking, if possible, towards the location of the monument. Where it is not available, the satellite view is shown instead.

Coordinates

Latitude: 52.7836 / 52°47'0"N

Longitude: -3.0855 / 3°5'7"W

OS Eastings: 326880.6037

OS Northings: 321220.5971

OS Grid: SJ268212

Mapcode National: GBR 72.XLZ8

Mapcode Global: WH794.K9XC

Entry Name: Lime kilns, associated tramways, structures and other buildings at Llanymynech

Scheduled Date: 14 July 2006

Source: Historic England

Source ID: 1021412

English Heritage Legacy ID: 36043

County: Shropshire

Civil Parish: Llanymynech and Pant

Built-Up Area: Pant

Traditional County: Shropshire

Lieutenancy Area (Ceremonial County): Shropshire

Church of England Parish: Llanymynech St Agatha

Church of England Diocese: Lichfield

Details

The monument includes a group of lime kilns, associated tramways, structures
and other buildings at Llanymynech. This industrial complex extends over
part of the south facing slope of Llanymynech Hill which itself has been
partly removed by the quarrying activities. Only a small part of the quarry
lies within England and in particular only a 170m length of the quarry face
forms part of this monument. A larger area of quarry floor complete with
small waste dumps and lengths of tramway embankment survives in Wales.

On the edge of the quarry are three separate lime kilns. These survive as
limestone rubble towers built into the side of the slope and containing two
or more bowl shaped brick lined kilns with a circular upper opening and a
second draw hole opening in the downslope side. Broken limestone and coal
were thrown into the upper openings to form alternate layers, whilst the
arched draw hole openings provided the necessary air flow for combustion and
access to the finished lime. These kilns were probably constructed in the
first half of the 19th century and may have continued in use until they were
replaced by the Hoffmann kiln in 1898. The limestone and coal would have
been transported to these kilns in wagons carried on a tramway system, much
of which still survives as embankments and cuttings. The burnt lime was
removed through the draw hole and carried in wagons on a tramway leading
either to the canal wharf or railway siding for loading onto barges or
trucks. The considerable difference in height between the upper quarry area
and the lower dispatch area meant that incline planes were needed to pull the
wagons up and down using gravity alone. This was achieved using drum houses,
one of which survives within the monument at NGR SJ26672171. The drum house
survives as a stone built structure with two 6m long parallel walls 2.2m
apart standing to a height of 3.75m. These walls are linked by two lateral
timbers and the remains of the braking system still survive. A lean-to
attached to the eastern wall of the house would have provided shelter for the
operator. The incline plane leading south from the drum house survives as a
clearly defined hollow denoted on either side by earthen banks. At the
foot of the incline plane the tramway passes under a stone bridge which still
carries the public highway between Welshpool and Oswestry. Beyond this the
tramway passes a tally hut where the contents of the wagons were recorded
before proceeding to the lower lime kilns, canal or railway. This two roomed
structure is brick built with a central chimney. Shortly after the tally hut
the tramway diverges, with the western branch leading to the canal wharf and
large draw kiln, whilst the eastern branch leads to the railway sidings and
Hoffmann Kiln. The large draw kiln includes two conjoined continuous
single draw limekilns. Both are of limestone rubble construction with brick
arched draw holes and the western one stands up to 8.5m high.

Immediately north east of these kilns is the large brick built Hoffmann Kiln
with its massive 140 foot high brick chimney. The kiln measures 44.8m long
by 17.5m wide, stands up to 3.4m high and has 14 chambers which were loaded
with limestone through the ground level arches. The interior of the kiln
takes the form of two parallel vaulted tunnels built side by side, connected
by curved tunnels at either end. The coal to fire the kiln was dropped in
through a series of small openings in the roof. The entire structure was
covered by a freestanding corrugated iron roof which no longer survives,
although at least one stanchion does. The Hoffmann kiln was built around
1898 and would have significantly increased the efficiency of the lime
burning operation at Llanymynech. The kiln was finally abandoned when lime
burning operations ceased in 1914.

Within the limeworks a number of further associated structures are known from
documentary and archaeological sources. The most prominent of these is the
stable block at NGR SJ26752117 in which horses used to pull the wagons were
housed. The building is believed to have been constructed around 1870 and
survives as a stone built structure with yellow brick-lined openings and
quoins. Its eastern elevation has a central doorway, with matching windows
and four ventilation slots, whilst on the north there is a loft opening and
three brick ventilation grids.

All modern trackway surfaces, protective fences, interpretation markers and
boards, benches, timber access stairs and temporary timber supports are
excluded from the scheduling, but the ground below them is included. The
stone bridge carrying the A483 over the monument is also excluded from the
scheduling, although the tramways below the bridge do form part of the
scheduling.

MAP EXTRACT
The site of the monument is shown on the attached map extract.

Source: Historic England

Reasons for Scheduling

Limestone or chalk has been the basic ingredient for lime mortar from at
least Roman times. Since the medieval period, lime has also been used as
agricultural fertiliser and, since the early 19th century, widely used in
a variety of other industries: as a flux in blast furnaces, in the
production of gas and oil, and in the chemical, pharmaceutical and food
industries.
The lime industry is defined as the processes of preparing and producing
lime by burning and slaking. The basic raw material for producing lime is
limestone or chalk: when burnt at high temperature (roasted or calcined),
these rocks release carbon dioxide, leaving `quicklime' which, by chemical
reaction when mixed with water (`slaking'), can be turned into a stable
powder - lime. Lime burning sites varied in scale from individual small
lime kilns adjacent to a quarry, to large-scale works designed to operate
commercially for an extended market and often associated with long
distance water or rail transport. Lime burning as an industry displays
well-developed regional characteristics, borne out by the regional styles
of East Anglia, West Gloucestershire or Derbyshire.
The form of kilns used for lime burning evolved throughout the history of
the industry, from small intermittent clamp and flare kilns, to large
continuously fired draw kilns that could satisfy increased demand from
urban development, industrial growth and agricultural improvement.
Small-scale rural lime production continued in the later 19th and 20th
centuries, but this period of the industry is mainly characterised by
large-scale production and the transfer of technologies from the cement
and other industries. The demand for mortars grew steadily during the 19th
and 20th centuries. The successful production of mortars made with
artificial cement represented an economic challenge to lime production and
gradually replaced the use of lime mortars in major construction and
engineering projects.
From a highly selective sample made at national level, around 200 lime
industry sites have been defined as being of national importance. These
have been defined to represent the industry's chronological depth,
technological breadth and regional diversity.


The lime kilns, associated tramways, structures and other buildings at
Llanymynech, together with adjacent Welsh quarries, form a particularly well
preserved and complete group of structures relating to a once relatively
widespread industry. In particular, the Hoffmann kiln represents the best
preserved example of its type in England and provides an additional component
found on very few other lime processing sites.

Source: Historic England

Sources

Books and journals
Jones, N W, Llanymynech Heritage Area Archaeological Survey, (2004)
Jones, N W, Llanymynech Heritage Area Archaeological Survey, (2004)
Jones, N W, Llanymynech Heritage Area Archaeological Survey, (2004)
Jones, N W, Llanymynech Heritage Area Archaeological Survey, (2004)
